HVAC Systems & Solutions | YONGFAN
HVAC Engineering Systems · 8 Complete System Routes · Integrated Component Architecture

Systems & Solutions: Engineered HVAC Component Interfaces

HVAC components should not be selected as isolated catalog items. The fan, filter, damper, heat exchanger, valve, water-treatment device and control point all have to work inside one operating system.

YONGFAN’s Systems & Solutions pages are organized around engineering interfaces across 8 core routes: Airside Ventilation, Cleanroom Filtration, Fire & Smoke Exhaust, Industrial Gas-Phase, Control Room Corrosion, Tunnel Ventilation, Hydronic Plant Rooms, and Heat Exchange & Water Treatment.

8 System Routes Airside to Hydronics
Air Filtration Pre-Filter to Gas-Phase
Ventilation Duty Normal, Fire, Tunnel
Plant Room Pressurization & Heat
Commercial central HVAC plant room showing coordinated pumps, heat exchangers, valves, and air handling equipment
Coordinated HVAC Systems Airside · Cleanroom · Fire Smoke · Gas-Phase · Tunnel · Hydronics · Heat Exchange
01 / System Interface Analysis

System Performance Depends On Interfaces Between Components

Catalog values only tell half the story. Real-world performance is governed by how pressure, aerodynamics, filtration stages, water chemistry, and control sequences interact.
Complex HVAC mechanical plant with coordinated ductwork, chillers, and piping
Interface-Driven Selection

Solving Component Interaction Bottlenecks Upfront

Matching duct pressure budgets, filtration sequences, emergency fire sequences, and hydronic expansion boundaries before model procurement.

Airside Resistance Bottlenecks

A fan meets its catalog airflow but starves index zones because coils, filters, silencers, and dampers add more pressure drop than estimated.

Impact: Under-ventilated occupied spaces & excessive fan speed noise

Cleanroom Filtration Bypass

A HEPA filter passes factory scans but the room misses cleanliness specs due to inadequate pre-filtration, bad casing seals, or room pressure loss.

Impact: Cleanroom qualification failure & short filter service life

Fire Damper Sequence Conflict

A normal 70 °C fire damper is mistakenly placed in a smoke exhaust path, shutting down emergency extract while the 280 °C smoke fan is running.

Impact: Catastrophic loss of emergency smoke extraction capability

Hydronic Expansion Misalignment

A booster pump skid is installed where closed-loop expansion control is needed, causing cyclic pressure loss and relief valve discharge.

Impact: Unstable hydronic pressure & chiller trip at part load

The 8 YONGFAN System Solutions

Start with the operating problem, then select the coordinated product families.

01 / Airside & Cleanroom Axial/Mixed-flow/Centrifugal fans, JG/T dampers, VAV, GFK/GCFK & FFUs
02 / Fire & Safety HTFC/DTF 280 °C fans, FHF 70 °C, PFHF 280 °C dampers & PYF smoke valves
03 / Gas-Phase & Corrosion PSA/PSA-PG fresh air, DBS/CA recirculation & WGP 100,000+ m³/h exhaust
04 / Hydronics & Heat JFDY, JFWP, JFHB, JFWZ, plate/tube exchangers & water treatment skids
02 / Portfolio Showcase

System Solutions Architecture Overview

Detailed overview of the eight engineering system routes offered by YONGFAN.
Route 01 · Airside Ducted Ventilation · Fans, Dampers & VAV

Airside Ventilation Systems

Coordinates axial (DTF/DTXF), mixed-flow (SWF 1,430–144,260 m³/h, 1,314 Pa), centrifugal (4-72), roof fans (DWT), DFS duct fans, JG/T 436 dampers, pressure-independent YFVAV-S-T100 terminals, YF-MOA plenums, and acoustic silencers into one balanced pressure chain.

Core Fans
SWF Mixed-Flow, DTF Axial, 4-72 Centrifugal
Airflow Control
JG/T 436 Dampers & YFVAV-S-T100 VAV
Distribution
YF-MOA Multi-Outlet Plenums
Acoustics
300 mm Attenuators & Acoustic Louvers
Primary Applications

Commercial office towers, industrial factories, shopping malls, transport hubs, and underground facilities.

Route 02 · Cleanroom Particle Control · GFK, GCFK & FFUs

Cleanroom Air Filtration Systems

Staged particle removal from coarse pre-filters (CG/CY) and medium filters (ZF bags, ZZH V-banks) to scan-tested terminal HEPA/ULPA filters, GFK passive supply boxes (500–3,000 m³/h), GCFK 150mm ultra-thin diffusers, and distributed FFU fan filter units (900 m³/h, ≤54 dB(A)).

Staged Filtration
G4 Pre + F8 Medium + H14/U15 HEPA
Passive Terminals
GFK & GCFK Ultra-Thin (150 mm)
Distributed Units
FFU Fan Filter Units (900 m³/h)
Pressure Control
Residual-Pressure Relief Dampers
Primary Applications

Semiconductor fabs, pharmaceutical GMP facilities, hospital operating suites, and precision electronics manufacturing.

Route 03 · Fire & Smoke Life Safety · 280 °C / 30 min · 3C Actuators

Fire & Smoke Exhaust Systems

Coordinated emergency smoke extraction and fire compartment isolation. Features HTFC centrifugal fan boxes (280 °C / 30 min dual-speed), DTF in-line axial smoke fans, FHF 70 °C fire dampers, PFHF 280 °C smoke-exhaust fire dampers, and PYF normally closed DC24V smoke valves.

Fire Fans
HTFC (1,400–171,000 m³/h) & DTF Axial
Compartment Dampers
FHF Normally Open (70 °C Fusible)
Smoke Path Dampers
PFHF Normally Open (280 °C Fusible)
Smoke Extract Valves
PYF Normally Closed (DC24V Signal Open)
Primary Applications

High-rise commercial buildings, shopping malls, underground parking basements, metro stations, and tunnels.

Route 04 · Gas-Phase Molecular Removal · Intake, Recirc & Exhaust

Industrial Gas-Phase Filtration

Targeted removal of gaseous molecules (H2S, SO2, Cl2, NOx, NH3, VOCs, mercaptans). Features PSA/PSA-PG fresh-air corrosion-control units (to 68,000 m³/h), DBS/CA indoor recirculation purifiers, and WGP industrial exhaust treatment systems (to 100,000+ m³/h) with deep carbon and chemisorption beds.

Fresh Air Intake
PSA (850–34,000 m³/h) & PSA-PG
Indoor Recirc
CA (850–6,800 m³/h MediaPAK) & DBS
Exhaust Treatment
WGP (Several thousand to 100,000+ m³/h)
Source Capture
OGP Wastewater Odor Enclosures
Primary Applications

Petrochemical refineries, wastewater treatment plants, hazardous waste storage, pulp & paper mills, and fine chemicals.

Route 05 · Corrosion Control Room Protection · ISA S71.04 G1

Control Room Corrosion Protection

Protects sensitive DCS, PLC, and server electronics from corrosive gas attack. Integrates PSA/PSA-PG treated fresh air, positive room pressurization, CA indoor recirculation scrubbers, motorized airtight intake shutoff (≤1.2 m³/(m²·h)), outdoor gas detector interlocks, and Cu/Ag reactivity monitoring.

Environmental Goal
ISA S71.04 Class G1 Severity
Airtight Intake
Motorized Low-Leakage Damper Interlock
Recirc Scrubbers
CA Series with Slide-In MediaPAK
Monitoring
Copper/Silver Coupons & Online Monitors
Primary Applications

Petrochemical central control rooms, data centers, substations, analyzer shelters, and pulp mill electrical rooms.

Route 06 · Tunnel Longitudinal Thrust · SDS Jet Fans & PYHL

Tunnel & Underground Ventilation

Aerodynamic momentum ventilation and ductless car-park extraction. Features SDS unidirectional jet fans (191–3,046 N static thrust, Ø630–1600mm), SDS(R) 30-second reversible jet fans, 1D/2D silencers (9–14 dB(A) attenuation), PYHL-14A 280 °C / 30 min induction exhaust, and DTF in-duct station fans.

Longitudinal Thrust
SDS & SDS(R) Reversible (191–3,046 N)
Ductless Car Parks
PYHL-14A Jet-Induction (280 °C / 30 min)
Ducted Metro/Basement
HL3-2A Mixed-Flow & DTF Axial
Acoustic Attenuation
1D & 2D Matched Diameter Silencers
Primary Applications

Highway road tunnels, railway/metro tunnels, underground parking garages, and large subterranean service complexes.

Route 07 · Hydronics Plant Room · Pressurization, Pumping & Valves

Hydronic Plant Room Systems

Coordinates closed-loop pressure maintenance (JFDY bladder tanks 0.20–8.53 m³, JFWP packaged expansion skids 48–480 m³ volume), constant-pressure water supply (JFHB 8–5,500 m³/h, JFWZ non-negative direct mains 8–280 m³/h), custom water manifolds (DN50–DN500), balancing valves, and 100X–900X hydraulic valves.

Pressure Maintenance
JFWP Integrated Skid & JFDY Vessel
Water Supply Boosting
JFHB (Break Tank) & JFWZ (Direct Mains)
Header Distribution
Water Distributors & Collectors (to 2.0 MPa)
Hydraulic Control
DRV/BYF Balancing & 100X–900X Pilot Valves
Primary Applications

Commercial central chiller/boiler plant rooms, district heating substations, high-rise booster stations, and industrial hydronics.

Route 08 · Heat Exchange Thermal Transfer & Water Quality · 0.21–21 MW

Heat Exchange & Water Treatment Systems

Pairs thermal heat exchangers with water treatment matched to water chemistry. Features gasketed plate heat exchangers (0.2–500 m²), packaged plate units (0.21–21 MW), JFSW turbulent tube exchangers, U-tube & floating coil storage exchangers (100–15,000 L), JFGP electronic water treatment, induction processors, and RLC softeners.

Plate Exchangers
Gasketed Packs (to 500 m²) & Skids (to 21 MW)
Tube & Storage
JFSW Double-Thread & U-Tube/Floating Coils
Physical Treatment
JFGP Inline & Broad-Spectrum Induction
Hardness Removal
RLC Automatic Ion-Exchange Softeners
Primary Applications

District heating substations, domestic hot water systems, cooling tower water loops, boiler feeds, and industrial heat recovery.

03 / Selection Routing

Systems & Solutions Selection Matrix

Match your engineering challenge to the appropriate YONGFAN system route and core product families.
Engineering ProblemSystem RouteYONGFAN Families Typically InvolvedFirst Variables to Confirm
Move and distribute normal ventilation airAirside Ventilation SystemsAxial, mixed-flow, centrifugal & roof fans; fan boxes; dampers; VAV; plenums; silencersAirflow, static pressure, sound, control, duct layout
Maintain particle-controlled clean airCleanroom Air Filtration SystemsPre-filters, medium filters, HEPA filters, GFK, GCFK, FFU, distribution & control dampersCleanliness target, airflow pattern, terminal type, DP
Extract smoke and isolate fire zonesFire & Smoke Exhaust SystemsSmoke fans/fan boxes (HTFC, DTF), FHF 70 °C, PFHF 280 °C, PYF smoke valves, actuatorsFire sequence, temperature duty, airflow, zone logic
Remove molecular contaminants from airIndustrial Gas-Phase FiltrationPSA, PSA-PG, DBS, CA, WGP and specialized carbon/chemisorption mediaTarget gases, concentration, airflow, intake/exhaust duty
Protect electronics from corrosive gasesControl Room Corrosion ProtectionPSA/PSA-PG, DBS/CA, airtight intake control, gas interlocks & corrosion monitoringRoom leakage, pressurization, gas profile, target G1
Drive air through tunnels & undergroundTunnel & Underground VentilationSDS/SDS(R) jet fans, PYHL induction fans, HL3-2A/DTF fans, 1D/2D silencersRequired thrust, tunnel geometry, emissions, fire mode
Maintain & distribute hydronic pressure/flowHydronic Plant Room SystemsJFDY, JFWP, JFHB, JFWZ, manifolds, balancing valves & 100X–900X hydraulic valvesFlow, pressure, system volume, source pressure, zoning
Transfer heat and manage water conditionHeat Exchange & Water TreatmentPlate/tube/storage exchangers, packaged units, JFGP, induction processors, RLC softenersHeat load, temperatures, fluid, water quality, pressure
04 / Procurement Protocol

Information Required for System Sizing & Selection

Provide the core engineering parameters for your project to route equipment into an integrated specification.
STEP 01

Engineering Problem

Select Airside, Cleanroom, Fire Smoke, Gas-Phase, Corrosion, Tunnel, Hydronics, or Heat Exchange.

STEP 02

Operating Duty

Provide design airflow/flow rates, pressures, thermal loads, or target cleanliness/corrosion classes.

STEP 03

System Interface

Define duct/piping geometry, power voltages, control signals (0–10V/Modbus/BACnet), and emergency modes.

STEP 04

Testing & Submittals

Specify project compliance standards (AMCA, ISO 16890, ISO 14644, ISA S71.04, 3C Fire, API 598, GB150).

Engineering Handoff

Submit System Requirements for Application Engineering Review

YONGFAN systems engineering team will review component interfaces, calculate pressure budgets, model thermal/aerodynamic behavior, and provide integrated submittal packages.

Target System Route: 01 to 08
Design Airflow (m³/h) or Water Flow (m³/h)
System Static Pressure / Pump Head (Pa / m)
Thermal Heat Load / Cooling Capacity (kW / MW)
Operating Environment: Normal, Fire, Corrosive, Ex
Control & Building Management Interface (BMS / DCS)
05 / Manufacturing QA

Interface Verification & System Quality Assurance

YONGFAN tests component assemblies to verified standards to ensure seamless integration on site.
Aerodynamic QA

AMCA Fan & Damper Testing

Fans and dampers verified for airflow, static pressure, dynamic balance, and acoustic regeneration.

Filtration QA

ISO & EN Filter Scans

Particulate filters tested to ISO 16890 / EN 1822; HEPA/ULPA 100% scan-tested for pinhole leaks.

Hydraulic QA

Pressure Vessel & Valve Tests

Exchangers and pressure vessels hydrostatically tested to 1.25–1.5× design pressure per GB150 and API 598.

Control QA

Actuator & Cabinet Bench Checks

Electric actuators, VFD skids, and control panels undergo functional signal sweep and interlock checks.

Component Dispatch: Standard stock components dispatched in 10–20 working days. Packaged Skids: Factory-assembled JFWP, JFHB, JFWZ, and heat exchange units tested before export crating.
06 / Engineering Knowledge

Systems & Solutions FAQ

Direct answers regarding system boundaries, turnkey claims, cleanroom ISO classes, and water treatment.

Where should I start if I only know the application?

Start with the engineering problem. Use Airside Ventilation for ducted air movement, Cleanroom for particle control, Fire Smoke for emergency duty, Gas-Phase for molecular gases, Hydronics for pressure/flow, and Heat Exchange for thermal duty.

Does YONGFAN supply a complete HVAC plant?

YONGFAN supplies coordinated equipment and component families. These pages help select compatible equipment, but do not claim turnkey central-plant EPC scope.

Can one filtration system handle both particles and corrosive gases?

Yes, by staging particulate filters (G4/F8/HEPA) with activated-carbon or chemisorption chemical media. Particles and molecular gases use different removal mechanisms.

Is a cleanroom HEPA terminal enough to define room cleanliness?

No. Terminal efficiency is only one part. Air-change rate, room pressurization, leakage, airflow distribution, and commissioning determine final ISO cleanliness.

Can a normal ventilation fan be used for smoke exhaust?

Only if documented and certified for high-temperature duty (such as 280 °C / 30 min). Smoke exhaust must be selected as a life-safety fire requirement.

Can PSA/PSA-PG be used instead of WGP?

No. PSA/PSA-PG treat incoming fresh air to protect indoor electronics. WGP is engineered for outgoing contaminated industrial exhaust streams.

What is the first number to compare for a tunnel jet fan?

Static thrust (N), followed by installed effective thrust which accounts for tunnel air velocity, spacing, and wall friction losses.

What is the difference between JFHB and JFWZ?

JFHB is a VFD constant-pressure booster for break tanks. JFWZ connects directly to municipal mains using non-negative-pressure technology.

Does water treatment replace heat-exchanger cleaning?

Water treatment dramatically reduces scaling and fouling, but exchangers still require scheduled inspection based on water quality.

07 / Application Boundaries

Systems & Solutions Engineering Boundaries

Clear boundaries governing system design, life safety, environmental targets, and site commissioning.
Boundary 01 / EPC Scope

Component Supplier

YONGFAN supplies equipment and component packages; building structural design, fire engineering, and EPC installation remain project responsibilities.

Boundary 02 / Cleanroom ISO

Room Qualification

Cleanroom terminals do not independently guarantee ISO 14644 room class without complete architectural envelope and commissioning verification.

Boundary 03 / ISA G1 Target

Facility Pressurization

Chemical filtration units are designed for ISA S71.04 Class G1 targets, but room sealing and positive pressurization are essential to prevent infiltration.

Boundary 04 / Municipal Approvals

JFWZ Mains Connection

Direct-mains boosting with JFWZ non-negative-pressure units is subject to local municipal water authority approval.

08 / Engineering Handoff

Plan Your Integrated HVAC System Solution

Connect with YONGFAN application engineers to coordinate fans, filtration, dampers, hydronic pressure maintenance, and heat transfer equipment into a reliable, high-performance specification.

Airside Ventilation (SWF, DTF, VAV, JG/T Dampers)Cleanroom Filtration (GFK, GCFK, FFU, HEPA/ULPA)Fire Smoke Exhaust (HTFC, DTF 280 °C, FHF, PFHF, PYF)Gas-Phase Filtration (PSA, PSA-PG, DBS, CA, WGP)Control Room Corrosion (ISA S71.04 G1, Airtight Dampers)Tunnel Ventilation (SDS Jet Fans 191–3,046 N, PYHL)Hydronic Plant Rooms (JFDY, JFWP, JFHB, JFWZ, Manifolds)Heat Exchange & Treatment (Plate, Tube, Storage, JFGP, RLC)
YONGFAN engineering team reviewing multi-system HVAC mechanical schematics
Comprehensive Engineering Support
Component matching, interface verification & integrated equipment submittals.
